The LFP12V series has high-level security protection to ensure the safety and reliability of the system in the whole life cycle;
the intelligent management structure design can accurately monitor the status of each component in the system to ensure the stable performance of the system
and the safety of users' electricity consumption.
+ Built-in lithium iron battery, 70% lighter than lead-acid battery.
+ Longer service life (6000 charging cycles, SLA is 500 times), direct manufacturer,
global technical support.
+ Low self-discharge rate and no memory effect; safety design to avoid short circuit,
overcharge and overdischarge, overcurrent and overheating.
| LiFePO4 | Nominal Voltage | Nominal Capacity | Nominal Energy | Max Charging current | Max Discharge current | 脉冲/3S | Dimensions（L*W*H) | Approx. Weight | Terminal | IP 等级 | 串联 | 蓝牙 | LCD | ||
| [V] | [Ah] | [Wh] | [A] | [A] | [A] | L [mm] | W [mm] | TH [mm] | [kg] | Type | |||||
| LFP12006 | 12.8 | 6 | 77 | 3 | 6 | 18 | 90 | 70 | 107 | 0.90 | F2 | IP50 | Y | P | P |
| LFP12008 | 12.8 | 8 | 102 | 4 | 8 | 24 | 151 | 65 | 94 | 1.10 | F2 | IP50 | Y | P | P |
| LFP12012 | 12.8 | 12 | 154 | 6 | 12 | 36 | 151 | 98 | 101 | 1.30 | F2 | IP50 | Y | P | P |
| LFP12020 | 12.8 | 20 | 256 | 10 | 20 | 60 | 181 | 77 | 167 | 2.00 | Insert M5 | IP50 | Y | P | P |
| LFP12030 | 12.8 | 30 | 384 | 15 | 30 | 90 | 195 | 130 | 168 | 3.60 | Insert M5 | IP50 | Y | P | P |
| LFP12040 | 12.8 | 40 | 512 | 20 | 40 | 120 | 195 | 130 | 168 | 5.60 | Insert M6 | IP50 | Y | P | P |
| LFP12050 | 12.8 | 50 | 640 | 25 | 50 | 150 | 229 | 138 | 213 | 6.30 | Insert M8 | IP50 | Y | P | P |
| LFP12060 | 12.8 | 60 | 768 | 25 | 50 | 150 | 229 | 138 | 213 | 9.40 | Insert M8 | IP50 | Y | P | P |
| LFP12080 | 12.8 | 80 | 1024 | 40 | 80 | 240 | 258 | 166 | 215 | 9.50 | Insert M8 | IP50 | Y | P | P |
| LFP12100-1 | 12.8 | 100 | 1280 | 50 | 100 | 300 | 258 | 166 | 215 | 13.00 | Insert M8 | IP50 | Y | P | P |
| LFP12100-2 | 12.8 | 100 | 1280 | 50 | 100 | 300 | 330 | 172 | 215 | 13.00 | Insert M8 | IP50 | Y | P | P |
| LFP12120-1 | 12.8 | 120 | 1536 | 50 | 100 | 300 | 330 | 172 | 220 | 13.50 | Insert M8 | IP50 | Y | P | P |
| LFP12120-2 | 12.8 | 120 | 1536 | 50 | 100 | 300 | 260 | 180 | 257 | 13.50 | Insert M8 | IP50 | Y | P | P |
| LFP12150 | 12.8 | 150 | 1920 | 50 | 100 | 300 | 330 | 172 | 220 | 20.00 | Insert M8 | IP50 | Y | P | P |
| LFP12200 | 12.8 | 200 | 2560 | 50 | 100 | 300 | 483 | 170 | 240 | 22.00 | Insert M8 | IP50 | Y | P | P |
| LFP12200 | 12.8 | 200 | 2560 | 50 | 100 | 300 | 522 | 240 | 220 | 22.00 | Insert M8 | IP50 | Y | P | P |
| LFP12300 | 12.8 | 300 | 3840 | 50 | 100 | 300 | 522 | 240 | 218 | 29.20 | Insert M8 | IP50 | Y | P | P |
| SY12-100 | 12.8 | 100 | 1280 | 50 | 100 | 500 | 600 | 270 | 65 | 15 | Anderson | IP30 | Y | P | Y |
| SY12-100 | 12.8 | 100 | 1280 | 100 | 200 | 1000 | 600 | 270 | 65 | 15 | Anderson | IP30 | Y | P | Y |
| SY12-200 | 12.8 | 200 | 2560 | 100 | 200 | 1000 | 850 | 275 | 70 | 28 | Anderson | IP30 | Y | P | Y |
