This series is designed for cyclic use.
Batteries of this series are made of special alloy and paste of lead, and allow for deep discharge cycles.
With a lean design, the batteries are sealed, maintenance-free, and can be installed in any direction.
+.Ultra-long discharge cycle
+.Used for power backup and energy storage
+.Special polar plate design, which ensures a long cycle file
+.High heat capacity, reducing risks of thermal runaway and dehydration, suitable for use in rigorous environments
+.High power density Good deep discharge performance
| Model | Voltage | Capacity | Dimension(mm) | Terminal | |||
| (V) | (Ah) | Length | Width | Height | Total Height | ||
| NTD12-10 | 12 | 10 | 151 | 98 | 95 | 101 | F1/F2 |
| NTD12-12 | 12 | 12 | 151 | 98 | 95 | 101 | F1/F2 |
| NTD12-17 | 12 | 17 | 181 | 77 | 167 | 167 | F13 |
| NTD12-20 | 12 | 20 | 181 | 77 | 167 | 167 | F13 |
| NTD12-24 | 12 | 24 | 175 | 166 | 125 | 125 | F13 |
| NTD12-33 | 12 | 33 | 195 | 130 | 155 | 168 | F11 |
| NTD12-40 | 12 | 40 | 197 | 165 | 170 | 170 | F11 |
| NTD12-45 | 12 | 45 | 197 | 165 | 170 | 170 | F11 |
| NTD12-55 | 12 | 55 | 229 | 138 | 208 | 213 | F11 |
| NTD12-65 | 12 | 65 | 350 | 167 | 179 | 179 | F11 |
| NTD12-75 | 12 | 75 | 258 | 166 | 210 | 215 | F21 |
| NTD12-80 | 12 | 80 | 350 | 167 | 179 | 179 | F11 |
| NTD12-90 | 12 | 90 | 306 | 169 | 210 | 215 | F21 |
| NTD12-100 | 12 | 100 | 330 | 171 | 215 | 220 | F12 |
| NTD12-120 | 12 | 120 | 410 | 176 | 227 | 227 | F12 |
| NTD12-134 | 12 | 134 | 341 | 173 | 283 | 287 | F12 |
| NTD12-150 | 12 | 150 | 482 | 170 | 240 | 240 | F12 |
| NTD12-175 | 12 | 175 | 530 | 209 | 215 | 220 | F12 |
| NTD12-180 | 12 | 180 | 522 | 238 | 218 | 223 | F12 |
| NTD12-200 | 12 | 200 | 522 | 238 | 218 | 223 | F12 |
| NTD12-250 | 12 | 250 | 520 | 269 | 221 | 227 | F12 |
