Easy to install and use
Multiple working modes
Fast and flexible charging
Scalability
| VESS48-5.0S-S1 | VESS48-10.0S-S1 | VESS48-15.0S-S1 | VESS48-20.0S-S1 | ||
| BATTERY | Battery Module | 1 | 2 3 | 4 | |
| Battery Energy | 5.12kWh | 10.24kWh | 15.36kWh | 20.48kWh | |
| Battery Capacity | 100AH | 200AH | 300AH | 400AH | |
| Weight | 80kg | 130kg | 190kg | 250kg | |
| Dimension L× D× H | 1190X600X184 | 1800X600X184 | 1800×600×184 690×600×184 | 1800×600×184 1300×600×184 | |
| Battery Type | LiFePO4 | LiFePO4 | LiFePO4 | LiFePO4 | |
| Battery Rated Voltage | 51.2V | 51.2V | 51.2V | 51.2V | |
| Battery Working Voltage Range | 44.8 ～ 57.6V | 44.8 ～ 57.6V | 44.8 ～ 57.6V | 44.8 ～ 57.6V | |
| Maximum Charging Current | 100A | 100A | 100A | 100A | |
| Maximum Discharging Current | 100A | 100A | 100A | 100A | |
| DOD | 80% | 80% | 80% | 80% | |
| Parallel Quantity | 1 | 2 | 3 | 4 | |
| Designed Life-span | 15years | 15years | 15years | 15years | |
| PV CHARGE | Solar Charge Type | MPPT | MPPT | MPPT | MPPT |
| Maximum Output Power | 5KW | 5KW | 5KW | 5KW | |
| PV Charging Current Range | 0~80A | 0~80A | 0~80A | 0~80A | |
| PV Operating Voltage Range | 120~500V | 120~500V | 120~500V | 120~500V | |
| MPPT Voltage Range | 120~450V | 120~450V | 120~450V | 120~450V | |
| AC CHARGE | Maximum Charge Power | 3150W | 3150W | 3150W | 3150W |
| AC Charging Current Range | 0 ~ 60A | 0 ~ 60A | 0 ~ 60A | 0 ~ 60A | |
| Rated Input Voltage | 220/230Vac | 220/230Vac | 220/230Vac | 220/230Vac | |
| Input Voltage Range | 90~280Vac | 90~280Vac | 90~280Vac | 90~280Vac | |
| INVERTER OUTPUT | Rated Output Power | 5KW | 5KW | 5KW | 5KW |
| Maximum Peak Power | 10KVA | 10KVA | 10KVA | 10KVA | |
| Power Factor | 1 | 1 | 1 | 1 | |
| Rated Output Voltage (Vac) | 230Vac | 230Vac | 230Vac | 230Vac | |
| Frequency | 50Hz | 50Hz | 50Hz | 50Hz | |
| Auto Switch Period | ＜15ms | ＜15ms | ＜15ms | ＜15ms | |
| THD | ＜3% | ＜3% | ＜3% | ＜3% | |
| GENERAL DATA | Communication | RS485/CAN/WIFI | RS485/CAN/WIFI | RS485/CAN/WIFI | RS485/CAN/WIFI |
| Storage time / temperature | 12 months @25℃; | 12 months @25℃; | 12 months @25℃; | 12 months @25℃; | |
| Charging temperature range | 0〜45℃ | 0〜45℃ | 0〜45℃ | 0〜45℃ | |
| Discharging temperature range | ‘-10〜45℃ | ‘-10〜45℃ | ‘-10〜45℃ | ‘-10〜45℃ | |
| Operation Humidity | 5% 〜 85% | 5% 〜 85% | 5% 〜 85% | 5% 〜 85% | |
| Nominal Operation Altitude | ＜2000m | ＜2000m | ＜2000m | ＜2000m | |
| Cooling Mode | Force-Air Cooling | Force-Air Cooling | Force-Air Cooling | Force-Air Cooling | |
| Noise | 60dB(A) | 60dB(A) | 60dB(A) | 60dB(A) | |
| Ingress Protection Rating | IP20 | IP20 | IP20 | IP20 | |
| Recommended Operation Environment | Indoor | Indoor | Indoor | Indoor | |
| Installation Method | Vertical | Vertical | Vertical | Vertical | |
| Certification | UN38.3,MSDS,EN55032,EN55024,EN61000-3-2,EN61000-3-3 | ||||
